Yerleşik Grafikler: Intel® Graphics Media Accelerator X4500 HD
Bellek: DDR3 1600/ 1333/1066 bellek
DIMM: 2 x Bellek Yuvası
LAN: Realtek 8105E 100 Mb/sn
Ses: Realtek 6 Kanallı Ses Codec'i
SATA: 4 x SATA bağlantı noktası, 1 x M.2 Yuva
Yerleşik Pin Başlıkları / Konektörler: 2 x USB 2.0 pin başlığı, ek 4 USB 2.0 bağlantı noktasını destekler 1 x Ön Panel Ses pin başlığı
Yuvalar: 1 x PCI Express x16 yuvası 1 x PCI E x1 yuvası
Form Faktörü: Mikro-ATX (21 x 21 cm)
Montaj: 6 montaj deliği
Spesifikasyon
INTEL H61
CPU Support
Intel® Socket 1155 for Intel Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Chipset
Intel H61 Chipset
On-Board Graphics
Intel® Graphics Media Accelerator X4500 HD
Memory
DDR3 1600/ 1333/1066 memory
DIMM
2 x Memory Slots
LAN
Realtek 8105E100 Mbps
Audio
Realtek 6 Channel Audio Codec
SATA
4 x SATA port, 1 x M.2 Port
ON-Board Pinheaders / Connectors
2 x USB 2.0 pinheader supports additional 4 USB 2.0 ports 1 x Front Panel Audio pinheader
Form Factor
Micro-ATX (21 x 21 cm)
Slots
1 x PCI Express x16 slot, 1 x PCI Express x1 slot
Mounting
6 mounting holes
Accessories
1 x SATA cable 1 x I/O Backboard 1 x User Manual 1 x Driver CD
Remark
All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. PCB color and bundled software versions are subject to change without notice. Brand and product names mentioned are trademarks of their respective companies.
